Guangdong Hanluo Environmental Protection Technology - Details of Direct Drinking Water Treatment System Products
Product Overview
Guangdong Hanluo Environmental Protection Technology's direct drinking water treatment system is a terminal drinking water solution that integrates multi-stage deep purification technology. It directly connects to municipal tap water. Through our patented composite process, it efficiently removes various harmful substances in the water while retaining beneficial minerals for the human body, producing fresh and healthy direct drinking water that meets or even exceeds the national "Drinking Purified Water Quality Standard" (CJ 94-2005). The system is applicable to various scenarios such as enterprise offices, schools, hospitals, hotels, communities, and factories, providing users with a high-quality drinking water experience that is safe, convenient and economical.
Core process technology (multi-stage barrier purification)
Our system is not merely a simple filtration process, but a complete three-level purification system of "pre-treatment + core purification + post-guarantee"
Pre-treatment level: Primary protection
PP cotton filter element: Effectively filters out large suspended particles such as rust, sediment and colloids in water, protecting the subsequent precision filter membrane.
Granular activated carbon filter core: Strongly adsorbs residual chlorine, discoloration, odor and some organic pollutants in tap water, improving the taste of water quality.
Core purification level: Deep purification
(Key) Reverse osmosis (RO) membrane element: It adopts imported/self-optimized high-performance RO membranes with a pore size of only 0.0001 microns, which can almost 100% remove bacteria, viruses, heavy metals (lead, cadmium, mercury, etc.), inorganic salts, pesticide residues, scale (calcium and magnesium ions), and dissolved organic matter from water, ensuring the core safety of the produced water.
Optional/Upgrade configuration: Nanofiltration (NF) membrane technology: For some customers who wish to retain an appropriate amount of minerals, we offer nanofiltration solutions. While efficiently removing harmful substances, it selectively retains some beneficial mineral ions, producing healthy direct drinking water that is closer to the quality of natural mineral water.
Post-treatment guarantee level: Taste optimization and sterilization
Post-activated carbon (CTO) : It further adsorbs the extremely trace amounts of odors that may exist, making the effluent taste sweeter and more refreshing.
UV ultraviolet sterilizer/ozone sterilization (optional) : Instantaneous sterilization of water at the outlet terminal eliminates the risk of secondary pollution in pipelines and ensures the biological safety of every drop of water.
Core advantages of the product
Ultimate safety: RO/NF dual-membrane technology ensures that the effluent quality can be monitored online, making safety visible.
Healthy and fresh: Scientific processes retain or add beneficial mineral elements, eliminating the health controversy of "pure water", and the water is fresh and ready to drink.
Intelligent and convenient: Fully automatic operation, automatic shutdown when water is low or full, intelligent reminder of filter element lifespan, and self-check for faults.
Energy conservation and environmental protection: Compared with bottled water, it eliminates secondary pollution and plastic waste. Compared with traditional water boilers, it can save up to 80% of energy.
Economical and durable: Made of food-grade 304 stainless steel or high-strength engineering plastics, the core components have a long service life, and the unit drinking water cost is only one-third of that of bottled water.
Comprehensive service: We offer a one-stop service covering "solution design - installation and commissioning - training - regular maintenance and filter element replacement - water quality tracking".
Technical parameters
Inlet water requirements: Municipal tap water (pressure: 0.1-0.4MPa)
Effluent quality: Complies with CJ 94-2005 "Drinking Purified Water Quality Standard"
Working environment: Temperature 5-40°C, humidity ≤80%
Rated voltage: 220V/50Hz
System recovery rate: ≥50% (water-saving design)
Application scenarios
Office buildings, government agencies, enterprises and public institutions
Schools, kindergartens, and educational training institutions
Hospitals, clinics, laboratories
Hotels, restaurants, cafes
Residential communities, villas, clubs
Water usage points in factory workshops and production lines
Our commitment
Guangdong Hanluo Environmental Protection Technology adheres to the concept of "establishing business with professionalism and meeting needs with responsibility", not only providing a piece of equipment, but also offering a lifelong maintenance solution for drinking water health. We promise that all our equipment has undergone strict factory tests and is provided with on-site services by professional engineers to ensure that you are at ease and worry-free in every step from installation to use.
