Product details description of ultrafiltration water treatment equipment
Product Name: High-Efficiency Ultrafiltration Water Treatment System
Core slogan: Physical barrier, ultimate filtration. We provide you with safe, stable and high-quality water.
Product Overview
Our high-efficiency ultrafiltration water treatment system adopts advanced ultrafiltration membrane technology and is a water purification solution centered on the physical screening principle. This system can efficiently remove impurities such as suspended solids, colloids, bacteria, viruses, and large-molecule organic substances from water, while retaining beneficial mineral elements for the human body.
With its features of high throughput, low energy consumption, automated operation and long-life membrane elements, the equipment has become an ideal choice in fields such as industrial pretreatment, advanced treatment of municipal water supply, drinking water purification and wastewater reuse.
Core technology and working principle
Technical principle: Hollow fiber ultrafiltration membranes are adopted, with pore sizes ranging from 0.01 to 0.1 microns. Under the drive of water pressure, water molecules and small molecules pass through the membrane wall to become "product water", while all particles larger than the membrane pore size, bacteria (>0.1µm), and most viruses (>0.01µm) are completely retained, achieving solid-liquid separation.
Filtration method: Cross-flow filtration or full-flow filtration mode can be selected, effectively reducing membrane fouling and adapting to different raw water qualities.
Automatic cleaning: Integrating air-water dual washing and chemically enhanced backwashing programs, it can effectively restore membrane flux and ensure the long-term stable operation of the system.
Product advantages
Outstanding effluent quality: The turbidity of the produced water is usually below 0.1 NTU, and SDI15 is less than 3, significantly reducing the load on subsequent treatment units (such as reverse osmosis), making it a perfect pre-treatment guarantee.
High-efficiency sterilization and disinfection: Pure physical filtration, no need to add additional chemical agents (such as chlorine), can almost 100% remove bacteria and most viruses, safe and without by-products.
Energy conservation and environmental protection: The operating pressure is low (usually 0.1-0.3 MPa), and the energy consumption is much lower than that of reverse osmosis systems. Physical processes do not alter the chemical properties of water.
Automation and intelligence: Equipped with a PLC automatic control system, it can achieve full automatic operation, timed backwashing, online monitoring and fault alarm, significantly reducing the cost of manual maintenance.
Compact modular design: The equipment has a compact structure and occupies a small area. The membrane module adopts a standardized module design, which is easy to expand, upgrade and maintain.
Long service life and low operating costs: High-quality PVDF (polyvinylidene fluoride) or PES (polyethersulfone) membrane materials have strong anti-pollution properties. Under standardized maintenance, their service life can reach over 3 to 5 years.
Typical application fields
Industrial field: Pre-treatment for reverse osmosis systems; Purification of cooling circulating water Preparation of process water Reuse of electroplating and coating wastewater.
Municipal and public Utilities: Advanced treatment of Waterworks; Safety guarantee for secondary water supply Direct drinking water systems in communities, schools and hotels.
Food and beverage industry: Purification of raw water; Bottled water production Water treatment for brewing.
Other fields: Pretreatment for seawater desalination; Swimming pool water circulation purification Water treatment for agricultural irrigation.
Technical parameter example
Membrane material: Hydrophilic PVDF/PES
Membrane pore size: 0.03 microns
Flux of a single membrane module: 1.0-3.0 m³/h (depending on model)
Operating pressure: 0.1-0.3 MPa
pH tolerance range: 2-11 (during chemical cleaning)
Maximum influent turbidity: < 15 NTU (recommended value)
Operating temperature: 5-45°C
Service and Commitment
We offer a full-process service covering on-site investigation, scheme design, equipment installation and commissioning, technical training and after-sales support. Our professional team ensures that every system can be put into operation in the best condition, creating long-term value for customers.
