Fully automatic Water Softening Treatment System - Product Details
Bid farewell to the trouble of scale, protect your equipment, and enhance quality and efficiency
Our fully automatic water softening treatment system is an intelligent solution specially designed to remove calcium and magnesium ions that cause scaling in water. Through advanced ion exchange technology, it converts "hard water" into "soft water", fundamentally solving the problem of scale and providing comprehensive protection for your equipment, pipelines and quality of life.
I. Core Issue: The Challenges Brought by hard Water
Hard water can lead to a series of costly problems in daily operations and life:
Equipment damage: Scale accumulates on the inner walls of boilers, heat exchangers, cooling towers, water heaters and other equipment, reducing thermal efficiency, increasing energy consumption, and ultimately leading to equipment damage and shortened service life.
Pipe blockage: Scale gradually clogs the pipes, reducing water flow, increasing pumping pressure and maintenance costs.
Increased cleaning costs: Soap scum residues cause stains on glassware and ceramic sanitary wares, requiring more cleaning agents and time. Textiles turn gray and become hard after washing.
Energy waste: Just 1.6 millimeters of scale can increase the fuel consumption of heating equipment by approximately 12%.
Ii. Working Principle: Intelligent Ion exchange
The core of the system is a tank filled with high-quality food-grade cation exchange resin. Automatic workflow loop
Softening: Hard water flows through the resin layer, where calcium and magnesium ions in the water exchange with sodium ions on the resin, producing high-quality soft water.
Regeneration (fully automatic) : When the adsorption capacity of the resin reaches saturation, the system automatically initiates the regeneration program based on the set time or flow rate. This process uses brine to clean the resin, displacing and discharging the captured calcium and magnesium ions, restoring the resin's softening capacity and automatically entering the next softening cycle. The entire process requires no human intervention.
Iii. Core Advantages of the Product
Efficient and intelligent control
Multi-way valve controller: It adopts imported/high-end multi-way valves, with high integration and stable and reliable operation.
Dual-mode triggering: Supports "time-type" and "flow-type" regeneration control, precisely matching your water usage patterns to achieve water and salt conservation.
LCD display: Friendly human-machine interface, real-time display of working status, remaining flow, regeneration time and other parameters, simple operation.
Outstanding performance and durability
High-quality resin: High exchange capacity, strong resistance to breakage, and long service life.
FRP tank body: Anti-corrosion and anti-rust, strong pressure-bearing capacity, suitable for various environments.
Food-grade material: All water-related components comply with hygiene standards and are safe and reliable.
One-stop integration: Standard salt tank, pipes and connectors, easy to install.
Significant economic benefits
Energy conservation: Prevent equipment scaling, maintain optimal thermal efficiency, and save up to 20% in energy costs.
Water conservation: Optimize the regeneration process to reduce backwash wastewater.
Extend equipment lifespan: Protect expensive downstream equipment and significantly reduce maintenance and replacement costs.
Reduce consumables: Decrease the use of chemicals such as cleaning agents and scale inhibitors.
Iv. Technical Parameters (Typical Configuration)
Processing flow rate: 1.0-100 m³/h (customizable according to requirements
Influent hardness: ≤ 8 mmol/L (Higher hardness requires special design)
Effluent hardness: ≤ 0.03 mmol/L (in compliance with national soft water standards)
Working pressure: 0.2-0.6 MPa
Operating temperature: 5-45 °C
Power supply: 220V / 50Hz
Connection diameter: DN20 - DN150 flange
V. Typical Application Fields
Industrial field: steam boilers, hot water boilers, central air conditioning cooling water, heat exchangers, humidification systems, process water for production.
Business sector: hotels, schools, hospitals, laundries, restaurants, beauty spas, office buildings.
Household field: Whole-house soft water for villas and high-end apartments, protecting floor heating, water heaters, faucets and water-related household appliances.
